- Resistant to chemical attack, abrasion and scratches.
- High quality insulation material
- Pre-assembled in factory as per requirements.
- Customized return-air duct & conduit for wiring
- Systems come with complete door and window sets, easy for installation.Multi-choice outer skins for wall & ceiling panel
- Powder coated galvanized steel sheet.
- Powder coated aluminum alloy sheet.
- Stainless steel sheet(wire-drawing/mirror finish)
- Melamine high pressure laminated (HPL) sheetMulti-choice insulation materials for wall & ceiling panel
- Rock wool
- Polystyrene (EPS/XPS)
- Fireproof paper honeycomb
- Aluminum honeycomb
- Polyurethane foam(PUF)
| General Performance | Wall Thickness | 50mm, 60mm, 75mm, 100mm | ||
| Regular Width | 1160mm,1180mm,900mm, Non-standard(customized) | |||
| Max Height | 8000mm, Non-standard(customized) | |||
| Main Material | Panel Material | PE, Anti-static, PVDF, Salinization, Stainless steel, Nanometer catalyst antibacterial plate, PVC coating | ||
| Filling Material | Rock wool, paper honeycomb, aluminum honeycomb, magnesium oxide, PU. | |||
| Connection | Aluminum alloy extrusion (2mm gap) |
Aluminum alloy extrusion (no silicone system) |
Aluminum alloy extrusion (8mm gap) |
|
| Fire Resistance | Aluminum alloy extrusion(8mm gap, 60 min fire resistance) | |||
| Applicable Place | Pharmaceutical clean room, electronic clean room, hospital operating room, food clean room, office partition. | |||
